imx6D uboot usb read issue

‎04-20-2018 03:24 AM
2,295 Views
jiujinhong
Contributor IV

Hi,

I met issue with USB R/W in bootloader. the program try to read 512M each, sometime it will fail with EHCI timeout, sometime it will success. I want to know if BSP pass USB large file R/W test or not.

If you can give some advice, please let me know, thanks.

U-Boot 2015.04-g45172a2 (Apr 18 2018 - 13:58:32)f

CPU:   Freescale i.MX6D rev1.5 at 792 MHz
CPU:   Temperature 54 C
Reset cause: POR
Board: MX6-SabreSD
I2C:   ready
DRAM:  2 GiB
PMIC:  PFUZE100 ID=0x10
MMC:   FSL_SDHC: 0, FSL_SDHC: 1, FSL_SDHC: 2
*** Warning - bad CRC, using default environment

No panel detected: default to Hannstar-XGA
Display: Hannstar-XGA (1024x768)
In:    serial
Out:   serial
Err:   serial
flash target is MMC:2
Fastboot: Normal
Net:   Phy 1 not found
FEC [PRIME]
Error: FEC address not set.

starting USB...
USB0:   USB EHCI 1.00
scanning bus 0 for devices... 2 USB Device(s) found
       scanning usb for storage devices... 1 Storage Device(s) found
       scanning usb for ethernet devices... 0 Ethernet Device(s) found
reading IMX6.bin
512 bytes read in 48 ms (9.8 KiB/s)
[UBOOT],200,77c00
[BOOTIMG],77e00,9c3800
[RECOVERY],a3b600,c26800
[SYSTEM],1661e00,1fc7b8b0
[VENDOR],212dd800,b6cb544
download uboot...
switch to partitions #1, OK
mmc2(part 1) is current device

MMC read: dev # 2, block # 0, count 2 ... 2 blocks read: OK
reading IMX6.bin
490496 bytes read in 92 ms (5.1 MiB/s)

MMC erase: dev # 2, block # 0, count 1024 ... 1024 blocks erased: OK

MMC write: dev # 2, block # 0, count 1024 ... 1024 blocks written: OK
download uboot success
switch to partitions #0, OK
mmc2(part 0) is current device

Partition Map for MMC device 2  --   Partition Type: DOS

Part    Start Sector    Num Sectors     UUID            Type
  1     16384           65536           00000000-01     83
  2     81920           65536           00000000-02     83
  3     147456          7024640         00000000-03     05 Extd
  4     7172096         53899264        00000000-04     83
  5     147457          3760127         00000000-05     83
  6     3907585         1048575         00000000-06     83
  7     4956161         16383           00000000-07     83
  8     4972545         8191            00000000-08     83
  9     4980737         4095            00000000-09     83
 10     4984833         4095            00000000-0a     83
 11     4988929         2047            00000000-0b     83
 12     4990977         2047            00000000-0c     83
 13     4993025         2097151         00000000-0d     83
download boot...
reading IMX6.bin
10237952 bytes read in 375 ms (26 MiB/s)

MMC erase: dev # 2, block # 16384, count 65536 ... 65536 blocks erased: OK

MMC write: dev # 2, block # 16384, count 65536 ... 65536 blocks written: OK
download boot success
download recovery...
reading IMX6.bin
12740608 bytes read in 462 ms (26.3 MiB/s)

MMC erase: dev # 2, block # 81920, count 65536 ... 65536 blocks erased: OK

MMC write: dev # 2, block # 81920, count 65536 ... 65536 blocks written: OK
download recovery success
download system...

MMC read: dev # 2, block # 147456, count 1 ... 1 blocks read: OK

MMC erase: dev # 2, block # 147456, count 3760128 ... 3760128 blocks erased: OK

MMC write: dev # 2, block # 147456, count 1 ... 1 blocks written: OK
download ...6%
reading IMX6.bin
EHCI timed out on TD - token=0x2c008d80
EHCI timed out on TD - token=0x2c008d80
EHCI timed out on TD - token=0x9c008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0xce008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0xcc008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0xbc008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0xbc008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0xbc008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0xbc008d80
EHCI timed out on TD - token=0x128d80
Error reading cluster
** Unable to read file IMX6.bin **
fatload usb 0 reserved system img failed
download vendor...

MMC read: dev # 2, block # 4993024, count 1 ... 1 blocks read: OK

MMC erase: dev # 2, block # 4993024, count 2097152 ... 2097152 blocks erased: OK

MMC write: dev # 2, block # 4993024, count 1 ... 1 blocks written: OK
download ...65%
EHCI timed out on TD - token=0x2008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0x2008d80
EHCI timed out on TD - token=0x128d80
EHCI timed out on TD - token=0x2008d80
EHCI timed out on TD - token=0x128d80
** Can't read partition table on 0:0 **
** Invalid partition 1 **
fatload usb 0 reserved vendor img failed
download ...100%
Please plug out usb mass strorage, and reset the board
8

U-Boot 2015.04-g45172a2 (Apr 18 2018 - 13:58:32)

CPU:   Freescale i.MX6D rev1.5 at 792 MHz
CPU:   Temperature 54 C
Reset cause: POR
Board: MX6-SabreSD
I2C:   ready
DRAM:  2 GiB
PMIC:  PFUZE100 ID=0x10
MMC:   FSL_SDHC: 0, FSL_SDHC: 1, FSL_SDHC: 2
*** Warning - bad CRC, using default environment

No panel detected: default to Hannstar-XGA
Display: Hannstar-XGA (1024x768)
In:    serial
Out:   serial
Err:   serial
flash target is MMC:2
Fastboot: Normal
Net:   Phy 1 not found
FEC [PRIME]
Error: FEC address not set.

starting USB...
USB0:   USB EHCI 1.00
scanning bus 0 for devices... 2 USB Device(s) found
       scanning usb for storage devices... 1 Storage Device(s) found
       scanning usb for ethernet devices... 0 Ethernet Device(s) found
reading IMX6.bin
512 bytes read in 48 ms (9.8 KiB/s)
[UBOOT],200,77c00
[BOOTIMG],77e00,9c3800
[RECOVERY],a3b600,c26800
[SYSTEM],1661e00,1fc7b8b0
download uboot...
switch to partitions #1, OK
mmc2(part 1) is current device

MMC read: dev # 2, block # 0, count 2 ... 2 blocks read: OK
reading IMX6.bin
490496 bytes read in 93 ms (5 MiB/s)

MMC erase: dev # 2, block # 0, count 1024 ... 1024 blocks erased: OK

MMC write: dev # 2, block # 0, count 1024 ... 1024 blocks written: OK
download uboot success
switch to partitions #0, OK
mmc2(part 0) is current device

Partition Map for MMC device 2  --   Partition Type: DOS

Part    Start Sector    Num Sectors     UUID            Type
  1     16384           65536           00000000-01     83
  2     81920           65536           00000000-02     83
  3     147456          7024640         00000000-03     05 Extd
  4     7172096         53899264        00000000-04     83
  5     147457          3760127         00000000-05     83
  6     3907585         1048575         00000000-06     83
  7     4956161         16383           00000000-07     83
  8     4972545         8191            00000000-08     83
  9     4980737         4095            00000000-09     83
 10     4984833         4095            00000000-0a     83
 11     4988929         2047            00000000-0b     83
 12     4990977         2047            00000000-0c     83
 13     4993025         2097151         00000000-0d     83
download boot...
reading IMX6.bin
10237952 bytes read in 390 ms (25 MiB/s)

MMC erase: dev # 2, block # 16384, count 65536 ... 65536 blocks erased: OK

MMC write: dev # 2, block # 16384, count 65536 ... 65536 blocks written: OK
download boot success
download recovery...
reading IMX6.bin
12740608 bytes read in 478 ms (25.4 MiB/s)

MMC erase: dev # 2, block # 81920, count 65536 ... 65536 blocks erased: OK

MMC write: dev # 2, block # 81920, count 65536 ... 65536 blocks written: OK
download recovery success
download system...

MMC read: dev # 2, block # 147456, count 1 ... 1 blocks read: OK

MMC erase: dev # 2, block # 147456, count 3760128 ... 3760128 blocks erased: OK

MMC write: dev # 2, block # 147456, count 1 ... 1 blocks written: OK
download ...6%
reading IMX6.bin
533182640 bytes read in 16436 ms (30.9 MiB/s)

MMC write: dev # 2, block # 147457, count 1041372 ... 1041372 blocks written: OK
download ...60%
download vendor...
vendor img is not exist to be download
download ...100%
Please plug out usb mass strorage, and reset the board

Labels (4)
Labels
0 Kudos
Reply
6 Replies

‎04-22-2018 08:24 PM
1,417 Views
jiujinhong
Contributor IV

https://community.nxp.com/thread/377911

0 Kudos
Reply

‎04-20-2018 04:18 PM
1,417 Views
igorpadykov
NXP Employee
NXP Employee

Hi jiu

issue may be caused by communications problems due to

noise or weak signal. One can try tests described in I.MX6/7 Series USB Certification Guide

http://www.nxp.com/assets/documents/data/en/user-guides/IMXUSBCGUG.pdf

USB layout in sect.3.12 USB recommendations i.MX6 System Development User’s Guide

https://www.nxp.com/docs/en/user-guide/IMX6DQ6SDLHDG.pdf

Best regards
igor

0 Kudos
Reply

‎09-18-2018 01:58 AM
1,417 Views
jiujinhong
Contributor IV

Hi igor, i have imx6d/6q/6dl boards and made test in 6dl board, it is very stable. So, can you give some good advice?

0 Kudos
Reply

‎09-13-2018 01:42 AM
1,417 Views
jiujinhong
Contributor IV

Hi Igor, this issue generated by U-boot otg driver, Linux OTG driver is very stable. I am very sure that fsl U-Boot 2015.04 BSP didn't test some large file READ/WRITE through usb otg.

0 Kudos
Reply

‎04-22-2018 07:35 PM
1,417 Views
jiujinhong
Contributor IV

We are sure that fsl bsp has some issue to support USB R/W with large files.  In the beginning, we found that EHCI will timeout if read 64MB/128MB file. later, we applied patch from google, it can R/W successfully in most of time.

0 Kudos
Reply

‎04-22-2018 07:06 PM
1,417 Views
jiujinhong
Contributor IV

Hi Sir,

I need to suggestion for SW, not some others. It seems that this issue can be easily caused by some disk. Some udisk seems stable.

my usbdisk info:


=> usb reset
resetting USB...
USB0:   USB EHCI 1.00
scanning bus 0 for devices... 2 USB Device(s) found
       scanning usb for storage devices... 1 Storage Device(s) found
       scanning usb for ethernet devices... 0 Ethernet Device(s) found
=> usb info
1: Hub,  USB Revision 2.0
 - u-boot EHCI Host Controller
 - Class: Hub
 - PacketSize: 64  Configurations: 1
 - Vendor: 0x0000  Product 0x0000 Version 1.0
   Configuration: 1
   - Interfaces: 1 Self Powered 0mA
     Interface: 0
     - Alternate Setting 0, Endpoints: 1
     - Class Hub
     - Endpoint 1 In Interrupt MaxPacket 8 Interval 255ms

2: Mass Storage,  USB Revision 2.10
 - SanDisk Ultra USB 3.0 4C530001271225121470
 - Class: (from Interface) Mass Storage
 - PacketSize: 64  Configurations: 1
 - Vendor: 0x0781  Product 0x5591 Version 1.0
   Configuration: 1
   - Interfaces: 1 Bus Powered 224mA
     Interface: 0
     - Alternate Setting 0, Endpoints: 2
     - Class Mass Storage, Transp. SCSI, Bulk only
     - Endpoint 1 In Bulk MaxPacket 512
     - Endpoint 2 Out Bulk MaxPacket 512

0 Kudos
