SSP DMA, rx buffer stays empty

Question asked by Gerard van den Bosch on Aug 8, 2016
Latest reply on Aug 9, 2016 by Gerard van den Bosch

Hello,



I am trying to get the SSP running with DMA on the LPC4357.

For this I configured 1 DMA channel for TX and 1 DMA channel for RX.



However the RX buffer always stays empty.



I have configured the DMA as following:

NVIC_DisableIRQ(DMA_IRQn);
NVIC_SetPriority(DMA_IRQn, ((0x01 << 3) | 0x01));
GPDMA_Init();

GPDMA_Channel_CFG_Type dma_txconfig;
dma_txconfig.ChannelNum = 0;
dma_txconfig.TransferSize = n;
dma_txconfig.TransferWidth = GPDMA_WIDTH_BYTE;
dma_txconfig.SrcMemAddr = (uint32_t)&txbuf;
dma_txconfig.DstMemAddr = 0;
dma_txconfig.TransferType = GPDMA_TRANSFERTYPE_M2P_CONTROLLER_DMA;
dma_txconfig.SrcConn = 0;
dma_txconfig.DstConn = GPDMA_CONN_SSP1_Tx;
dma_txconfig.DMALLI = 0;
GPDMA_Setup(&dma_txconfig);

GPDMA_Channel_CFG_Type dma_rxconfig;
dma_rxconfig.ChannelNum = 1;
dma_rxconfig.TransferSize = n;
dma_rxconfig.TransferWidth = GPDMA_WIDTH_BYTE;
dma_rxconfig.SrcMemAddr = 0;
dma_rxconfig.DstMemAddr = (uint32_t)&rxbuf;
dma_rxconfig.TransferType = GPDMA_TRANSFERTYPE_P2M_CONTROLLER_DMA;
dma_rxconfig.SrcConn = GPDMA_CONN_SSP1_Rx;
dma_rxconfig.DstConn = 0;
dma_rxconfig.DMALLI = 0;
GPDMA_Setup(&dma_rxconfig);

Channel0_TC = 0;
Channel0_Err = 0;
Channel1_TC = 0;
Channel1_Err = 0;

NVIC_EnableIRQ(DMA_IRQn);
GPDMA_ChannelCmd(0, ENABLE);
SSP_DMACmd(spip->ssp, SSP_DMA_TX, ENABLE);

GPDMA_ChannelCmd(1, ENABLE);
SSP_DMACmd(spip->ssp, SSP_DMA_RX, ENABLE);

while (((Channel0_TC == 0) && (Channel0_Err == 0)) || ((Channel1_TC == 0) && (Channel1_Err == 0)));



My SPI is configured for 8bit, so I setup the DMA Transferwidth to the same.

This is inside my SPI send function, so 'n' will be the amount of bytes to be transferred.

The Channel0_TC and Channel1_TC are set correctly to 1 in the DMA interrupt.

But the rxbuf configured for the RX DMA stays empty...



Anyone a pointer what might go wrong here?



Cheers,

Gerard

dma_txconfig.SrcConn = 0;
