We are pleased to announce that MCUXpresso Config Tools v7 are now available.



MCUXpresso Configuration Tools is a product with set of tools that help users of all levels with a Cortex-M-based MCU solution.

Features

  • Available as Web, Desktop application and MCUXpresso IDE plug-ins
  • MCUXpresso SDK v2 support
  • Multicore support
  • GUI localized for English and Simplified Chinese
  • On-Demand device data download for latest features and support
  • Integrated directly within MCUXpresso IDE, standalone version supports other compilers and IDEs
  • Currently there are the following tools available:


Downloads



Revision History

7.0.1

  • Mac OS X 10.15 operating system support added.

  • TEE tool: Displays correctly inaccessible regions in "Memory attribution map" view.7.0

7.0

  • Added "Help | Kit/Board Information" option that displays information about currently used kit or board.
  • Clickable Part number, Board and Kit name supported. It displays information about currently used processor, board and kit.
  • Data Manager - supports clearing locally cached processors, boards, kit and components content.
  • Configuration Preferences - supports custom copyright in generated sources
  • TEE tool: Memory map is now interactive, cell double click opens its configuration.
  • TEE tool: Memory map now displays peripherals space details.
  • TEE tool: Added possibility to import memory configuration from MCUXpresso IDE project(s).
  • TEE tool: Memory regions in Access overview are now grouped by memory type; all memory region aliases are displayed in a single row.
  • TEE tool: Pins table now contains pin labels from the Pins tool.
  • TEE tool: Additional validations and security setting recommendations.
  • Peripherals tool: Tool can now generate binary output files.
  • Peripherals tool: Component name is derived from the selected peripheral by default. It can be overwritten by a user.
  • Peripherals tool: Documentation view improvements related to navigation added two new features - header with links in documentation content and selection box in header of view.
  • Peripherals tool: Deprecated components have "(deprecated)" suffix in the add component dialog if there are still other instances of this type in configuration.
  • Pins tool: Added automatic routing feature which can be used for conflict resolution in the current functional group.
  • (MCUXpresso Config Tools only): Preferences - Added Dark theme support
  • (MCUXpresso IDE only): Added SEMC/SDRAM stress tests, with RT support.
  • (MCUXpresso IDE only): Added FlexSPI/NOR Validation tool, with RT support.


Community

MCUXpresso Config Tools





MCUXpresso Config Tools Data

The Data for MCUXpresso Config Tools v7 was successfully deployed on the production system.



What’s new in data

The Data for MCUXpresso Config Tools v7 release provides following updates:

  • 330 Kinetis, LPC and i.MX processors and 229 boards supported in total.
  • Updated code generated by Pins, Clocks and Peripherals tool to support SDK v2.7 API.
  • Peripherals tool support added for LPC8N04, KV11/4x/5x, KExx, KV3x and K22 (FN1M0 and FX512 memory variants only) processors. 200 processors supported by Peripherals tool in total - all processors in SDK v2.7 are supported by Peripherals tool now.
  • Added 21 new Peripherals tool components for various Kinetis, LPC and i.MX RT processors. 103 components are available now in total.
  • Improved DMA support in Peripherals tool - edma and lpc_dma components updated to support transactional and non-transactional modes, improved support of DMA request settings in other Peripherals tool components.
  • Improved interrupt settings in Peripherals tool components, added default interrupt subroutine snippets.
  • Added new Audio 1.0 and Device Firmware Update classes to USB Peripherals tool component, supported suspend/resume/remote wake-up feature, improved PHDC class support and USB endpoint settings.
  • Added support of Memory validation for i.MX8MM processors, maintenance update of Memory validation/DDR tool supporting RT1020, RT1050, RT1060, RT1064 and i.MX8MM processors.
  • Updated TEE tool for LPC55S6x processors.
